Mouvex A Series
SubCategory: EccentricDiscPumps
Manufacturer: Mouvex
Industry: Aviation;Chemical;Docks;OilGas;PaintSurfaceCoating;Petrochemical;PowerGeneration;Transportation;Refineries;PaintResinProduction
Key specifications
- Flows up to 55 m³/h
- Pressure up to 10
Description
Performance
• Exceptional Self-Priming capabilities
• Legendary ruggedness
• The A series pumps maintain their initial performance level over
• time without any adjustment, thanks the automatic clearance
• make-up system
• Unchanging characteristics
• Maintain a regular and constant output, independent of the
• delivery pressure
• Practically unlimited scope of application
• Reversibility
• Excellent efficiency
Options
• Double by-pass for protection when operating in both directions
• High temperature: HT version for AF and AK models enable
• high temperature transfer (up to 250° C)
• Heating or cold jacket for transferring products that can solidify
• at ambient temperature.
Products 7

Mouvex A55
Capacity 55 m³/h
Pressure 10 bar

Mouvex A31
Capacity 31 m³/h
Pressure 10 bar

Mouvex A18
Capacity 18 m³/h
Pressure 10 bar

Mouvex A12
Capacity 11.7 m³/h
Pressure 10 bar

Mouvex A6
Capacity 5.7 m³/h
Pressure 10 bar

Mouvex AD
Capacity 2.3 m³/h
Pressure 5 bar

Mouvex AZ
Capacity 1.2 m³/h
Pressure 5 bar
