Realax IP Series

Hose pumps up to 25 m3/hr

Key specifications

  • Flows up to 42 m³/h
  • Pressure Up To 8 bar

FEATURES AND BENEFITS

  • Suction lift to 9 metres.
  • Reversible rotation.
  • Can be accompanied with pulsation dampeners.
  • Hose leakage detector available.
  • FDA materials available.
  • Available with casing coated in Halar (PTFE).`

Description

A suite of industrial hose pumps that utilise shoes to compress the hose rather than rollers giving a more even and longer sealing area. They are fitted with inverter driven motors and have sturdy reinforced hoses.


Products 7

Realax IP-80

Capacity 42 m³/h
Pressure 8 bar

Realax IP-70

Capacity 18.5 m³/h
Pressure 8 bar

Realax IP-70D

Capacity 35 m³/h
Pressure 8 bar

Realax IP-60

Capacity 10 m³/h
Pressure 8 bar

Realax IP-50

Capacity 5 m³/h
Pressure 8 bar

Realax IP-40

Capacity 3.4 m³/h
Pressure 8 bar

IP-30

Capacity 1.7 m³/h
Pressure 8 bar

Let us help you find the right product from this product line

Construction

Alignment
Horizontal
Seal
Seal-Less
Coupled
Close

Performance

Max. capacity
42 m³/h
Max. diff. press.
8 bar
Max. temperature
65 °C
Min. viscosity
1 mPa·s

Certificates

ATEX

CE Marking

FDA pumps, valves, mixers, homogenizers, heat exchangers and spare parts

Downloads

Operating Instructions Manual
